3DG

The L3GD20 is a low-power three-axis angular rate sensor.

Key Features

• Three selectable full scales (250/500/2000 dps)
• User-selectable bandwidth
• I2 C/SPI digital output interface
• 16 bit-rate value data output
• 8-bit temperature data output
• Two digital output lines (interrupt and data ready)
• Integrated low- and high-pass filters with user-selectable bandwidth
• Wide supply voltage: 2.4 V to 3.6 V
• Low voltage-compatible IOs (1.8 V)
• Embedded power-down and sleep mode
• Embedded temperature sensor
• Embedded FIFO
• High shock survivability
• Extended operating temperature range (-40 °C to +85 °C)
